GQ-Charger Tester

 The GQ-Charger Tester is an All-in-One portable electric vehicle charging test equipment that supports charging sequence tests and insulation resistance tests for DIN70121, ISO15118, and CHAdeMO standards.

• Supported Standards: DIN70121, ISO15118
• Optional: CHAdeMO
• DC Loader Options: External or Built-in (2kW)
• Voltage Measurement Accuracy: 0~1000V ± 1%
• Current Measurement Accuracy: 0~200A ± 1%
• Interfaces: USB, RS232, Banana Jack (CP, PD)
• Portable Test Equipment : Vehicle-mountable carrier type
